High-Quality 10*60W RGBW Super Dotline LED Waterproof Lamp DL1060IP - China Suppliers Factory for Stage Lighting Suppliers, Supplier

Introducing our Professional Zoom Wash Beam Pixel Bar Light, a top-tier lighting solution manufactured in China. This exceptional light features 10 pieces of 60W RGBW 4-in-1 LEDs, ensuring powerful output with remarkable color purity and consistency. Designed for versatility, it supports multiple control modes, including DMX, RDM, master/slave, sound active, and auto, along with 4 dimming curves for seamless 0~100% dimming capabilities, Our state-of-the-art tilt and zoom motors operate quietly, swiftly, and with high precision, while the advanced linear dimming system provides unparalleled dimming effects. Ideal for DJs, discos, and various performance venues, this product adds a dazzling light show to your stage. As a reliable supplier in the industry, our factory prioritizes quality and innovation, making this lighting bar a must-have for any professional setup. Experience the brilliance of our pixel bar light and elevate your performances today!

Product Description

Product Application

Technical Specifications

💡 Light Source

  • Beam Section: 10x60W RGBW LED
  • Strobe Section: 96 x 3W CW LED; 96 x 3W WW LED; 96 x 0.5W RGB LED
  • Total Lumen Output: 23,000 lumens
  • Life Expectancy: 20,000 hours

🔍 Optical System

  • Beam Angle: 2.8°-31° (Beam section)
  • Field Angle: 5°-46° (Beam section)
  • Zoom: Motorized Zoom

🔄 Pan & Tilt

  • Tilt Movement: 200° (16bit)
  • Correction: Automatic Tilt position correction

⚡ Effects

  • Pixel Control: Pixel control of main LED
  • Sections: 12 individual sections
  • Strobe: 1-25Hz or random Beam, wash effects

⚙️ Software & Control

  • Programs: Multiple built-in programs
  • Upgrade: Upgrade with DMX
  • Channels: 17/27/99/108/168CH
  • Remote Reset: DMX address and fixture by DMX
  • Control Protocol: DMX512, RDM protocol
  • Signal: Input signal isolation

🖥️ Display

  • Display Type: LCD display
  • Control Panel: 4 buttons touch panel

⚡ Electric Parameter

  • Voltage: AC100-240V 50/60HZ
  • Power: 860W

📏 Dimension & Weight

  • Product Size: 1000 x 290 x 120mm
  • Net Weight: 23KG

Product Features

🌟 Powerful Light Source & Pure Color

Equipped with professional light sources and expansive clear lenses, ensuring powerful light output with exceptional color purity and consistency.

🔇 Silent & Efficient Motors

Tilt and zoom motors operate silently, rapidly, and with high precision, providing a smooth visual experience for your stage performances.

📉 Advanced Dimming System

Features an advanced linear dimming system that delivers a flawless dimming effect, outperforming comparable offerings.

🎮 Multi-Function Control Modes

Supports DMX, RDM, Master/slave, Sound Active, and Auto modes, catering to diverse stage needs.

🔎 Flexible Zoom & Color Mixing

Adjustable zoom angle and excellent color mixing effects allow you to create visual spectacles as you wish.

🛡️ High-Quality Durable Materials

Manufactured with high-quality materials, with an LED lifespan of up to 30,000 hours, ensuring long-term stable stage performance.

Frequently Asked Questions

Q What is the light output and source configuration of this LED lamp?

The fixture delivers a total lumen output of 23,000 lumens. Its light source includes a Beam Section with 10x60W RGBW LEDs and a Strobe Section configured with 96 x 3W CW LEDs, 96 x 3W WW LEDs, and 96 x 0.5W RGB LEDs.

Q What is the zoom range and movement capability of the fixture?

It features a motorized zoom with a beam angle of 2.8°-31° and a field angle of 5°-46°. The tilt movement has a range of 200° (16bit) with automatic tilt position correction.

Q Which control protocols and DMX channels does it support?

The fixture supports DMX512 and RDM protocols, with input signal isolation. It operates on multiple DMX channel modes: 17CH, 27CH, 99CH, 108CH, and 168CH.

Q What are the physical dimensions and electrical requirements?

The product size is 1000 x 290 x 120mm with a net weight of 23KG. It operates on AC100-240V 50/60HZ with a power consumption of 860W.

Q How long is the expected lifespan of the light source?

The fixture's light source features a high-quality design with a life expectancy of 20,000 hours under standard specifications, extending up to 30,000 hours due to the durable materials utilized.
